Features: Metro: Live Remote Mixing Over Internet, 33 Touch-Sensitive Motorized Faders, 32 XMAX Preamps: 16 Mic and 16 Mic/Line, 16 Analog FlexMix Outs: 12 XLR and 4 TRS, Integrated 64x64 USB Audio Interface, Powerful Dual-Core FLEX DSP Engine, Onboard 32-Track SD Recorder, Dynamic Fat-Channel Layout, Built-In AVB Networking, Full-Color Touchscreen
Number of Analog Input Channels: 32
Number of Mic Preamps: 32
Mix Routing: 26x Bus
Faders & Level Adjustment: 33 Fader
Gain/Trim Range: Mic:0 dB to +60 dB
EQ: Input Channels:4-Band EQ Outputs:6-Band EQ
Solo/Mute: Solo - Mute per Input Channel
Sample Rates: 44.1 / 48 kHz
Bit Depth: AD/DA Conversion:24-Bit
DSP: Dual-Core 32-Bit Floating Point
Converter Dynamic Range: 115 dBA at 48 kHz
Jitter: < 20 ps RMS
Jitter Attenuation: > 60 dB
Latency: 1.9 ms (Analog Input to Analog Output)
dBFS Reference Level: +18 dBu = 0 dBFS
Frequency Response: Headphone Output:20 Hz to 20 kHz ±0.5 dB Mic/Line Input to Main Output:20 Hz to 20 kHz ±0.5 dBu (2901653073)
Max Input Level: Mic Input:+12 dBu Line Input:+18 dBu Tape Input:+12 dBu
Headphone Output Power: 100 mW per Channel into 60 Ohms
I/O Impedance: Mic Input:1 Kilohms Line Input:10 Kilohms XLR Output:100 Ohms Line Output:100 Ohms Tape Output:100 Ohms
Crosstalk: Input to Output:-90 dB Adjacent Channels:-87 dB
CMRR: 65 dB at Unity Gain
SNR: Mic/Line Input to Main Output:94 dBA at Unity Gain (+4 dBu Reference)Headphone Output:96 dB at Max Gain
THD: Mic/Line Input to Main Output:< 0.005% at Unity Gain (+4 dBu - 2901653246)
THD+N: Headphone Output:0.01% at Max Gain (Unweighted)
Analog Inputs: 1x XLR Talkback Input16x XLR 3-Pin Mic Input16x Combo XLR-1/4-inch TRS Mic/Line Input4x 1/4-inch TRS Aux Return (2 Stereo Pairs)1x Stereo RCA Tape Input (1 Stereo Pair)
Analog Outputs: 1x Stereo RCA Tape Output (1 Stereo Pair)12x XLR 3-Pin Subgroup/Aux/Matrix Output4x 1/4-inch TRS Subgroup/Aux/Matrix Output2x XLR 3-Pin Main Output1x XLR 3-Pin Mono-Summed Output2x 1/4-inch TRS Monitor Output1x 1/4-inch TRS Headphone Output4x 1/4-
Phantom Power: +48 V ±2 V (Selectable on Individual Inputs)
Digital I/O: 1x RJ45 (Control - 1 Gb/s)1x RJ45 AVB (I/O)1x XLR AES3 Output
MIDI I/O: No
USB I/O: 1x USB-B 2.0()
Wireless: Bluetooth 4.1
OS Compatibility: macOS 10.8.5 or Later Windows 7 Windows 8.1 Windows 10 10 or Later 5.0 or Later
Processor Requirement: Intel Core 2 Duo
RAM Requirements: 4 GB - 8 GB Recommended
Storage Requirements: 30 GB
Mobile Device Compatibility: iPad Android Smartphone Android Tablet
Minimum Display Resolution: 1366 x 768
Internet Connection: Yes
Required Hardware: Available USB 2.0 Port
Input Power: 90 to 230 VAC - 50 / 60 Hz
Power Consumption: 85 W
Lamp Power: 12 VDC
Rack Mountable: No
Operating Temperature: 32 to 104 degreesF / 0 to 40 degreesC
Dimensions: 32.4 x 23 x 6.5-inch / 82.2 x 58.3 x 16.5 cm
Weight: 37.2 lb / 16.9 kg
